Spinosaurus EVO
SPINOSAURUS EVO is the ultimate extensible camera with a latest FPGA Xilinx Zynq Ultrascale+ and with high speed imaging sensor. It incorporates high performance ARM 64 bit system-on-chip (SOC) technology, combined with latest SONY GEN3 PREGIUS industrial CMOS imaging sensors. High speed industrial Ethernet 10G or 40G connection to host PC.
With full HSDK source code and with high performance FPGA system-on-chip (SoC) technology, SPINOSAURUS opens new dimensions in embedded computer vision and artificial intelligence. It is a global shutter industrial camera with very high frame rates, with range of readymade image processing cores and with wide options for custom functions integration.
No need to spend time to develop camera from a scratch. Just add your own image processing core to SPINOSAURUS EVO.
From: 0 €
- Freely programmable
- 600 Gbps FPGA platform IO banwidth
- 12 lanes Sony SLVS-EC v2.0 ready (5 Gbits)
- High speed H.264 CODEC
- Neural network interface acceleration
- Exploits maximal capability of imaging sensor
- Possible interfaces: 10/40GigE, USB3.0, 4xPCIe, DisplayPort
- Freely extensible
- Full source code included
- Xilinx Vivado tool chain
- Stereo remote head
- Remote SFP for OEM
- C-mount housing (IP67 option)
- 3D multiline laser triangulation core
- BLOB detection core
- Running length image compressor
